DPH Series 15-105 kVA (208V) - Modulon Family

Product code :

Fully integrated power solutions in one 42U cabinet for small data center applications

The Modulon DPH supports ultimate availability for datacenter operations and provides the benefit of “pay as you go” without over-sizing the UPS. While achieving ultimate availability, the Modulon DPH does not compromise on power efficiency performance. When availabil- ity, efficiency and expanding according to business needs are essential, the Modulon DPH is the ideal UPS system to provide power protection and total cost of ownership (TCO) savings.

Price: Contact Us

Counseling support: +84-979933470

DPH series 15-105kVA UPS

T.A.T International Company Limited is an authorized Distributor of Delta Electronics

DPH Series 15-105 kVA (208V) - Modulon Family

Features and Benefits

High Integration and Space Saving

Fully integrated in one 42U cabinet with power supply, battery runtime, static transfer switch and input/output/bypass breakers, not extra solution

Ultimate Availability

	Fully modularized design and hot-swappable modules for easy deployment and maintenance
	Redundant aux power and controller design
	Dual CAN bus to ensure the inherent reliability on signal level
	Battery module’s LED fuse warning indicators can alert operators in the event of a blown fuse

Excellent Power Performance

	Industry-leading high power density of power module: 15kVA/kW in 2U height
	AC-AC conversion efficiency 95% and ECO mode efficiency up to 98.5% with Energy star 2.0 certificated
	Green mode for effective utilization

High Manageability

	Environment Management System integration (optional)
	Power consumption trend calculation
	Inbuilt Ethernet and RS485 communication interface
	User-friendly 10” touch panel
