ZGTT5N-10 Antenna Feeder SPD

General
The ZGTT5N-10 Antenna Feeder SPD is mainly applicable to the antenna feeder of the radio communication station, suppressing induced lightning waves from the antenna feeder, and thus protecting electronic equipment. In this way, the damage caused by induced lightning waves, abnormal power supply and static discharge from the antenna feeder can be avoided.

Standards Complied
Q/75875187-9·4—2011    Antenna Feeder SPD

Technical Data

Model	ZGTT5N-10
Applicable power	300W
Nominal discharge current I_n (8/20μs)	5kA
Max. discharge current I_max (8/20μs)	10kA
Limiting voltage (10/70μs)	≤100V
Operating frequency	130MHz～470MHz
Insertion loss	≤0.2dB
VSWR	≤1.2
Characteristic impedance of port	50Ω
Model of port (input/output)	N-50K, N-50J
Degree of protection	IP20
