The differences between RG6, RG11 and RG59
RG Coaxial Cables are widely used in Telecom projects as well as daily civil works. RG Coaxial Cables include many types in which the most popular type is RG6, RG11 and RG9 Coaxial Cables. How different are these three types? It will be shown below.
RG Coaxial cables are the type of coaxial cable which are used for effective transmission solutions for Telecom systems such as Satellite communication, Marine, Mobile communication, the systems of AM, FM, Inbuilding, Rada Communication, Video….
RG Coaxial Cables include: RG174, RG59, and RG 8 X, RG213, RG6 and RG11. RG11, RG6, RG59 are widely used and used in most of Telecom projects and civil works.
The differences among RG11, RG6 and RG59
RG6 Coaxial Cables are used for Base band with near signal transmission distance, often used as a cable branch to transmit observing camera data and connect Indoor Television Equipment.
RG11 Coaxial Cables are used for Wide Broadband with far signal transmission distance, often used as a main cable line in transmitting observing camera data, Cable Television, etc.
RG59 Flexible Coaxial Cables: With the feature of intertwined multi - small fibers which makes the fibers flexible; therefore, this is a type of Coaxial Cables which is mainly used for observing camera in elevators, normally used for analog camera.
RG6 and RG11 Coaxial Cables have the same applications used with different distance. So, what makes them different?
RG6 has higher attenuation level; RG11 has lower attenuation level.
RG6 can transmit signals in a higher frequency range than RG6.
Because RG11 has lower attenuation level, it can transmit in a father distance: RG6 can transmit signal in a distance of 600m, RG11 can transmit in a distance of 1,100m.
The weak point of RG11 is high price because bigger thickness of cable fibers and conductor wire make the cost of materials higher. That’s the reason why RG11 is more expensive than RG6.
Another weak point of RG11 is lack of flexibility which is caused by the thickness of fibers. RG11 Coaxial Cables are not able to bend so much with different angles, so RG11 is often used as a main line in connecting two points in a far distance.
RG Coaxial Cables of Kingsignal are the high-quality products but their price is reasonable. Hence, RG Coaxial cables of Kingsignal are widely used in Telecom projects, signal transmission in the world.
In Vietnam, T.A.T is an exclusive distributor of Kingsignal with the variety of products such as Feeder Coaxial Cables, RG Coaxial Cables, Telecom Cables and other Telecom accessories.
More details of RG Coaxial Cables of Kingsignal here.
